Davey Submersible Grinder Pumps

Davey Submersible Grinder Pumps

Submersible pumps with inbuilt macerator, these grinder pumps are able to pump soft solids in suspension by shredding it to a slurry.

This product is available in more than one type or model. Please view the range below.

Davey Submersible Grinder Pumps Single Phase Models

D120G – 1.2kW
D150G – 1.5kW
D120GA – 1.2kW with automatic float switch D150GA – 1.5kW with automatic float switch

SKU: Davey Submersible Grinder Pumps Single Phase Models


Davey Submersible Grinder Pumps Three Phase Models

DT12G – 1.2kW
DT15G – 1.5kW
DT22G – 2.2kW
DT37G – 3.7kW





Call us on 08 8162 5957 for pricing on this product

SKU: Davey Submersible Grinder Pumps. Categories: , , .

Davey Submersible Grinder Pumps

Davey submersible grinder pumps consisting of a solids handling grinder inlet with a high head open impeller to pump waste water containing soft solids in suspension

Applications
  • Grey Water Pumping
  • Sump Emptying
  • Septic Effluent & Sewage Water Disposal
  • Pumping of waste water with soft solids in suspension.
Features
  • Heavy duty shredding and grinding ring at inlet.
  • Centrifugal design, open impeller.
  • Able to pump soft organic solids, sanitary products, thin rubber products and even some textiles in suspension, by shredding to a slurry.
  • Open impeller prevents blockage of the pump by small solids in the slurry.
  • High heads and small solids allow connection to small discharge pipe systems, especially suited to pumping waste water to pressure sewer mains.
  • Double Mechanical shaft seal in oil bath.
  • Hard faced Silicon Carbide/Ceramic seal on pump side.
  • Sand slinger lip seal for added protection.
  • Oring casing sealing.
  • Corrosive resistant stainless steel and quality heavy duty powder coated cast iron pump parts.

Download Brochure Here



Products specifications

Maximum Flow 290 lpm
Maximum Pressure 38 m head
Power Output 1.2 – 3.7 kW
Power Supply SinglePhase, 240 Volt AC, 50 Hz
Power Supply Three Phase,415 Volt AC, 50 Hz
Motor Speed 2 Pole (3000 rpm)
Warranty Period 1 Year
