Davey ISOspec Engine-Driven Pumps

80 Series Engine-Driven Pumps

High quality, fully packaged ISO spec pump packaged to the commercial Yanmar TNV diesel engine series. Designed to international standards ISO2858 ensuring a sturdy, reliable, long lasting, and high performing product.



Call us on 08 8162 5957 for pricing on this product

SKU: Davey ISOspec Engine-Driven Pumps. Categories: , , .

Davey ISOspec Engine-Driven Pumps

Applications

Davey ISOspec Diesel driven pumpsets are ideal for:

  • Water Supply
  • Commercial Irrigation
  • Booster Stations
  • Municipal Water Supply
  • General Transfer
  • Dust Suppression

Features

  • Bronze wear rings: Fitted as standard, replaceable front & rear wear rings with optional materials, for a trouble free lifecycle.
  • Bronze impeller: In a closed design is fitted as standard to prevent corrosion in stationary or inactive situations.
  • Pump Casing: High efficiency Cast Iron volute casings.
  • Casing o-ring: Reusable orings in Nitrile for ease of re-assembly.
  • Back pull-out design: Allowing for easy removal of rotating element without disturbing the pipework, lagging, motor or pump volute casing. This is proven to reduce downtime whilst performing routine maintenance.
  • Enlarged shaft: Reduces shaft deflection.
  • Shaft seal: Single, high quality John Crane or approved equivalent mechanical seal with carbon vs ceramic fitted as standard with other options such as Silicon vs Silicon hard face/high temperature mechanical seal also available.
  • Tappings: Convenient suction & discharge pressure gauge tappings plus volute drain, fitted as standard to all ISOspec series pumps.
  • Bearings: Heavy duty SKF or approved equivalent, greased for life, reducing maintenance. Housed within removable bearing cap cover assembly, protected by a quality manufactured lip seal reducing ingress of moisture or foreign matter.
  • Bearing housing: Robust / heavy duty, manufactured in high strength cast iron providing trouble free life cycle.



Download Brochure Here

Products specifications

Maximum Flow 450 m3/hr
Maximum Pressure 160 m head
Engine Power 8 – 100 hp
Engine Brand Yanmar
Fuel Type Diesel
