CMG PPD Series Electric Motor

PPD Series Electric Motor

The PPD range of Motors is specifically designed for Ex d hazardous locations, containing any sparks within the motor without igniting external vapors.

Call us on 08 8162 5957 for pricing on this product

SKU: CMG PPD Series Three Phase Electric Motor. Categories: , .

CMG PPD Series Electric Motor

CMG PPD Series Electric Motor are certified for use in Zone 1 hazardous locations. These motors are designed to contain any sparks within the motor without igniting external vapours. They incorporate features such as a robust cast iron construction and special terminal box to meet the stringent certification requirements.

The complete PPD range covers sizes 80 to 280, three phase 2, 4, 6 & 8 pole, with foot and flange mounting options.

Features

  • Ex d, Zone 1, Group I and IIB, T4 Temperature Class
  • Three Phase
  • Cast Iron
  • IP66
  • Class F Insulation
  • Up to 1100 volts
  • Top Mounted Terminal Box
  • Foot or Flange Mounting
  • Low Noise

 Standards

  • International Standard IEC 60072
  • Australian and New Zealand Standard AS/NZS 1359

 Applications

  • Hazardous Areas





Products specifications

Power Output 0.55 – 90 kW
Power Supply Three Phase,415 Volt AC, 50 Hz
Motor Speed 2 Pole (3000 rpm)
Motor Speed 4 Pole (1500 rpm)
Motor Speed 6 Pole (1000 rpm)
Motor Speed 8 Pole (750 rpm)
Mount Type B3 Foot Mount
Mount Type B5 Flange Mount (Large)
Mount Type B14 Flange Mount (Small)
Mount Type B3/B5 Foot & Flange Mount
Hazardous Area Types Ex’d’
